322,26 zł
Shaft block
| Class description short | Shaft block |
| Mass netto | 0.105 kg |
| Width | 53.0 mm |
| REACH | REACH compliant for SVHC free linear products (acc to PL responsibles) |
| RoHS | RoHS compliant |
| Brand | INA |
| Diameter | 16.0 mm |
| Height | 42.0 mm |
| Length | 24.0 mm |
| Lower tolerance | 0.15 mm |
| Mounting Dimension | 26.5 mm |
| Mounting Dimension | 40.0 mm |
| Mounting Dimension | 25.0 mm |
| Mounting Dimension | 26.6 mm |
| Mounting Dimension | 5.4 mm |
| Mounting Dimension | 21.0 mm |
| Mounting Dimension | 26.0 mm |
| Mounting Dimension | 16.0 mm |
| Mounting Dimension | 6.6 mm |
| Mounting Dimension | 11.0 mm |
| Mounting Dimension | 5.0 mm |
| Mounting Dimension | 18.0 mm |
| Mounting Dimension | 38.0 mm |
| PFAS | nein |
| Tolerance | H8 |
| Upper tolerance | 0.01 mm |
| Upper tolerance | 0.01 mm |
| Lower tolerance | 0.01 mm |
| Lower tolerance | 0.01 mm |
| Upper tolerance | 0.15 mm |
| Width across Flat | 4.0 mm |
| Mounting thread below | M8 |
| Size code | 16 |
| Size thread fixing screws above | M6 |
| Version | B |
