322,75 zł
Carriages KWVE..-B-E, standard carriage, four-row, full complement, expanded type
| Class description short | Recirculating ball bearing carriage |
| Mass netto | 225.0 g |
| REACH | REACH compliant for SVHC free linear products (acc to PL responsibles) |
| Accuracy class | G3 |
| Brand | INA |
| Position lubrication connector | 4.3 mm |
| Position lubrication connector | 3.2 mm |
| Thread depth | 7.0 mm |
| Maximum permissible screw depth for lubrication connectors | 5.5 mm |
| Maximum permissible screw depth for lubrication connectors | 5.5 mm |
| Lubrication connector | M3 |
| Distance from locating edge to hole | 5.5 mm |
| Distance from locating edge on carriage to locating edge on guideway | 18.5 mm |
| Free space, system dimension | 4.3 mm |
| Height system | 24.0 mm |
| Overall length carriage | 61.2 mm |
| Dynamic load rating | 7200.0 N |
| Static load rating | 14500.0 N |
| Material name | KWVE |
| Static moment rating about X axis | 150.0 Nm |
| Static moment rating about Y axis | 100.0 Nm |
| Static moment rating about Z axis | 100.0 Nm |
| PFAS | nein |
| Position lubrication connector | 11.1 mm |
| Preload class | V1 |
| Maximum tightening torque | 5.0 Nm |
| Width carriage | 52.0 mm |
| Width rail | 15.0 mm |
| Carriage design | E |
| Lubrication connector | M3 |
| Size code | 15 |
| Fixing screws below (DIN ISO 4762-12.9) | M4 |
| Version | B |
