INA
| Średnica wewnętrzna d | 300mm |
|---|---|
| Średnica zewnętrzna D | 380mm |
| Masa | 11,6kg |
| Temperatura pracy | -30…80 °C |
| Basic dynamic load rating, radial (for radial load only) | 174 000N |
|---|---|
| Basic static load rating, radial (for radial load only) | 485 000N |
| Running accuracy, axial | 0,01mm |
| Basic dynamic load rating, axial | 245 000N |
| Basic static load rating, axial | 990 000N |
| Dimensions identical to ISO dimension series 18 | 61 860 |
| Inner diameter outer ring | 340,8mm |
| Bore diameter lower tolerance |
22 377,40 złnetto
+ VAT 23% = 27 524,20 zł brutto
Dobierz 9 szt., żeby zejść do 21 258,53 zł
| od 1 szt. | — | 22 377,40 zł |
| od 10 szt. | −5% | 21 258,53 zł |
| od 50 szt. | −8% | 20 587,21 zł |
| od 250 szt. | −12% | 19 692,11 zł |
Cena schodzi automatycznie po przekroczeniu progu w koszyku.
Faktura z terminem 30 dni · dostawa kurierem albo paletowa
| -0,027mm |
| Bore diameter upper tolerance | 0,005mm |
|---|
| Rolling element pitch circle diameter | 340mm |
|---|
| Diameter of lubrication hole | 2,5mm |
|---|
| Height of the assembled bearing | 38mm |
|---|
| Height of individual ring | 38mm |
|---|
| Height inner ring | 38mm |
|---|
| Height of individual ring lower tolerance | -0,05mm |
|---|
| Height of individual ring upper tolerance | 0mm |
|---|
| Limiting speed for grease lubrication with normal clearance | 225 1/min |
|---|
| Limiting speed for oil lubrication with normal clearance | 450 1/min |
|---|
| Outer diameter inner ring | 339,2mm |
|---|
| Maximum axial tilting clearance, at standard bearing clearance | 0,08mm |
|---|
| Maximum radial bearing clearance, at standard bearing clearance | 0,04mm |
|---|
| Low clearance: Preload | 0,01mm |
|---|
| Low clearance: Radial clearance | 0,005mm |
|---|
| Minimum axial tilting clearance, at standard bearing clearance | 0,02mm |
|---|
| Minimum radial bearing clearance, at standard bearing clearance | 0,01mm |
|---|
| Chamfer dimension | 2,1mm |
|---|
| Outside diameter lower tolerance | -0,036mm |
|---|
| Outside diameter upper tolerance | 0mm |
|---|
| Running accuracy, radial | 0,02mm |
|---|
| Width lower tolerance | -0,14mm |
|---|
| Width upper tolerance | 0,14mm |
|---|
