1309,34 zł
Miniature Guideway; for Miniature-Carriage, Standard and Long design
| Class description short | Miniature Guideway for Miniature-Carriage, Standard design |
| Mass netto | 0.223 kg |
| REACH | REACH compliant for SVHC free linear products (acc to PL responsibles) |
| Accuracy class | G2 |
| Brand | INA |
| Distance between start of guideway and nearest hole | 11.0 mm |
| Distance between end of guideway and nearest hole | 11.0 mm |
| Distance between start of guideway and nearest hole | 4.0 mm |
| Distance between end of guideway and nearest hole | 4.0 mm |
| ~Guideway length | ~1000 |
| Height | 4.8 mm |
| Increment | 15.0 mm |
| Length | 2.3 mm |
| Material name | TKDM |
| Max length single piece guideway | 1000.0 mm |
| Size code | 07 |
| Thread | M2 |
| Tightening torque | 0.32 Nm |
| Version | E |
| Width rail | 7.0 mm |
