INA
| Średnica wewnętrzna d | 136mm |
|---|---|
| Średnica zewnętrzna D | 259,36mm |
| Obciążenie dynamiczne C | 84 000N |
| Obciążenie statyczne C₀ | 270 000N |
| Masa | 7,1kg |
| Temperatura pracy | -25…80 °C |
| Basic dynamic load rating, axial | 93 000N |
|---|---|
| Basic static load rating, axial | 670 000N |
| Inner diameter outer ring | 189mm |
| Bore diameter lower tolerance | -0,5mm |
| Bore diameter upper tolerance | 0,5mm |
| Diameter centring outer ring | 238mm |
| Diameter centring inner ring | 135mm |
| Diameter centring inner ring lower tolerance | 0 |
9260,80 złnetto
+ VAT 23% = 11 390,78 zł brutto
Dobierz 9 szt., żeby zejść do 8797,76 zł
| od 1 szt. | — | 9260,80 zł |
| od 10 szt. | −5% | 8797,76 zł |
| od 50 szt. | −8% | 8519,94 zł |
| od 250 szt. | −12% | 8149,50 zł |
Cena schodzi automatycznie po przekroczeniu progu w koszyku.
Faktura z terminem 30 dni · dostawa kurierem albo paletowa
| Diameter centring inner ring upper tolerance | 0,2mm |
|---|
| Diameter centring outer ring lower tolerance | -0,07mm |
|---|
| Diameter centring outer ring upper tolerance | 0mm |
|---|
| Height | 35mm |
|---|
| Height of inner ring | 30mm |
|---|
| Length centering inner ring | 10mm |
|---|
| Length centering outer ring | 4mm |
|---|
| Max. tooth force against tooth fracture (at a shock factor of 1,35) | 15 300N |
|---|
| Max. tooth force root fatigue strenght (at a shock factor of 1,2) | 10 400N |
|---|
| Normal axial clearance max. | 0,2mm |
|---|
| Normal radial clearance max. | 0,1mm |
|---|
| Max. radial load fixing screws (friction locking) | 44 800N |
|---|
| Normal axial clearance min. | 0,05mm |
|---|
| Normal radial clearance min. | 0,03mm |
|---|
| Modul of gearing | 4mm |
|---|
| Number of teeth | 62 |
|---|
| Outside diameter inner ring | 187mm |
|---|
| Pitch circle diameter gearing | 248mm |
|---|
| Pitchcircle diameter fixing holes inner ring | 154mm |
|---|
| Pitchcircle diameter fixing holes outer ring | 222mm |
|---|
| Profile shift | 2mm |
|---|
| Number of fixing holes in inner ring | 16 |
|---|
| Number of fixing holes in outer ring | 16 |
|---|
| Thread depth fixing hole | 20mm |
|---|
| Tread fixing bore | M10 |
|---|
| Width gearing | 26mm |
|---|
| Width outer ring | 30mm |
|---|
| Gearing | V |
|---|
