INA
| Średnica wewnętrzna d | 240mm |
|---|---|
| Średnica zewnętrzna D | 384mm |
| Obciążenie dynamiczne C | 123 000N |
| Obciążenie statyczne C₀ | 270 000N |
| Masa | 13,7kg |
| Temperatura pracy | -25…80 °C |
| Basic dynamic load rating, axial | 136 000N |
|---|---|
| Basic static load rating, axial | 590 000N |
| Bore diameter lower tolerance | -0,5mm |
| Bore diameter upper tolerance | 0,5mm |
| Diameter centring outer ring | 310mm |
| Diameter centring inner ring | 238mm |
| Diameter centring inner ring lower tolerance | -0,07mm |
| Diameter centring inner ring upper tolerance |
19 851,90 złnetto
+ VAT 23% = 24 417,84 zł brutto
Dobierz 9 szt., żeby zejść do 18 859,31 zł
| od 1 szt. | — | 19 851,90 zł |
| od 10 szt. | −5% | 18 859,31 zł |
| od 50 szt. | −8% | 18 263,75 zł |
| od 250 szt. | −12% | 17 469,67 zł |
Cena schodzi automatycznie po przekroczeniu progu w koszyku.
Faktura z terminem 30 dni · dostawa kurierem albo paletowa
| Diameter centring outer ring lower tolerance | -0,08mm |
|---|
| Diameter centring outer ring upper tolerance | 0mm |
|---|
| Height | 32mm |
|---|
| Height of inner ring | 30mm |
|---|
| Length centering inner ring | 18mm |
|---|
| Length centering outer ring | 3mm |
|---|
| Max. tooth force against tooth fracture (at a shock factor of 1,35) | 16 100N |
|---|
| Max. tooth force root fatigue strenght (at a shock factor of 1,2) | 11 000N |
|---|
| Normal axial clearance max. | 0,26mm |
|---|
| Normal radial clearance max. | 0,16mm |
|---|
| Max. radial load fixing screws (friction locking) | 82 600N |
|---|
| Normal axial clearance min. | 0,07mm |
|---|
| Normal radial clearance min. | 0,04mm |
|---|
| Modul of gearing | 4mm |
|---|
| Number of teeth | 94 |
|---|
| Outside diameter inner ring | 302,3mm |
|---|
| Pitch circle diameter gearing | 376mm |
|---|
| Pitchcircle diameter fixing holes inner ring | 262mm |
|---|
| Pitchcircle diameter fixing holes outer ring | 343mm |
|---|
| Number of fixing holes in inner ring | 20 |
|---|
| Number of fixing holes in outer ring | 20 |
|---|
| Thread depth fixing hole | 18mm |
|---|
| Tread fixing bore | M12 |
|---|
| Width gearing | 30mm |
|---|
| Width outer ring | 30mm |
|---|
| Gearing | N |
|---|
