| Class description short | Adjusting gib |
| Mass netto | 4.5 kg |
| Width | 75.0 mm |
| REACH | REACH compliant for SVHC free linear products (acc to PL responsibles) |
| RoHS | RoHS compliant |
| Adjustment max | 0.5 mm |
| Adjustment per screw revolution | 0.075 mm |
| Brand | INA |
| Core hole | 9.0 mm |
| For linear roller bearing | RUS65210 |
| Height min | 38.0 mm |
| Adjustment screw hexagon socket | 12.0 mm |
| Locking/extraction screw hexagon socket | 5.0 mm |
| Length max | 234.0 mm |
| Lower tolerance | 0.1 mm |
| Lower tolerance | 0.1 mm |
| Max | 220.0 mm |
| Max | 10.0 mm |
| PFAS | nein |
| Tightening torque | 83.0 Nm |
| Tightening torque | 41.0 Nm |
| Tightening torque | 41.0 Nm |
| Upper tolerance | 0.1 mm |
| Upper tolerance | 0.1 mm |
| Fixing screws DIN ISO4762-12.9 | M10 |
| Fixing screws DIN ISO4762-12.9 | M8 |
| Fixing screws DIN ISO4762-12.9 | M8 |
| Size code | 65210 |
