42 017,05 zł
Axial/radial bearings, double direction, screw mounting, for higher speeds, with integrated angular measuring system
| Class description short | Axial/radial roller bearing |
| Mass netto | 17.514 kg |
| Operating temperature min. | -30.0 °C |
| Operating temperature max. | 120.0 °C |
| Basic dynamic load rating, radial | 110000.0 N |
| Basic static load rating, radial | 305000.0 N |
| Limiting speed | 910.0 1/min |
| REACH | REACH conform |
| RoHS | RoHS compliant |
| Axial rigidity of rolling element set | 16800.0 N/µm |
| Axial and radial runout, measurement standard; Measured on mounted bearing, with ideal adjacent construction. | 6.0 µm |
| Axial rigidity of bearing position | 9700.0 N/µm |
| Basic dynamic load rating, axial | 173000.0 N |
| Basic static load rating, axial | 1050000.0 N |
| Bore diameter | 260.0 mm |
| Bore diameter lower tolerance | -0.018 mm |
| Bore diameter upper tolerance | 0.0 mm |
| Brand | INA |
| Counterbore depth of fixing holes | 8.2 mm |
| Counterbore diameter of fixing holes | 15.0 mm |
| Fixing holes diameter inner ring | 9.3 mm |
| Fixing holes diameter outer ring | 9.3 mm |
| Height contact face outer ring | 36.5 mm |
| Height contact face outerring H1 lower tolerance | -0.07 mm |
| Height contact face outerring H1 upper tolerance | 0.05 mm |
| Height contact face outer ring | 18.5 mm |
| Height | 55.0 mm |
| Height shaft washer | 13.5 mm |
| Angular measuring system integrated | M |
| Mass moment of inertia for rotating inner ring | 2074.0 kg*cm² |
| Mass moment of inertia for rotating outer ring | 1422.0 kg*cm² |
| Maximum diameter inner ring | 347.0 mm |
| Outside diameter | 385.0 mm |
| Outside diameter lower tolerance | -0.02 mm |
| Outside diameter upper tolerance | 0.0 mm |
| PFAS | nein |
| Pitch quantity | 36.0 |
| Pitch separation angle | 10.0 ° |
| Pitch circle diameter fixing holes in inner ring | 280.0 mm |
| Pitch circle diameter fixing holes in outer ring | 365.0 mm |
| Quantity of fixing holes inner ring | 34.0 |
| Quantity of fixing holes outer ring | 33.0 |
| Quantity of retaining screws | 2.0 |
| Quantity of threaded extraction hole | 3.0 |
| Radial rigidity of rolling element set | 5800.0 N/µm |
| Radial rigidity of bearing position | 6400.0 N/µm |
| Diameter of dimensional scale on shaft locating washer | 343.69 mm |
| Screw tightening torque | 34.0 Nm |
| Threaded extraction hole | M12 |
| Tilting rigidity of rolling element set | 201000.0 Nm/mrad |
| Tilting rigidity of bearing position | 120600.0 Nm/mrad |
| Width of outer ring | 18.0 mm |
