INA
| Średnica wewnętrzna d | 15mm |
|---|---|
| Średnica zewnętrzna D | 60mm |
| Szerokość B | 25mm |
| Masa | 0,428kg |
| Temperatura pracy | -30…120 °C |
| Axial runout | 2µm |
|---|---|
| Basic dynamic load rating, axial | 19 800N |
| Basic static load rating, axial | 28 500N |
| Bearing frictional torque | 0,2Nm |
| Bore diameter lower tolerance | -0,005mm |
| Bore diameter upper tolerance | 0mm |
| Connection thread for lubrication | M6 |
| Contact angle | 60° |
1434,20 złnetto
+ VAT 23% = 1764,07 zł brutto
Dobierz 9 szt., żeby zejść do 1362,49 zł
| od 1 szt. | — | 1434,20 zł |
| od 10 szt. | −5% | 1362,49 zł |
| od 50 szt. | −8% | 1319,46 zł |
| od 250 szt. | −12% | 1262,10 zł |
Cena schodzi automatycznie po przekroczeniu progu w koszyku.
Faktura z terminem 30 dni · dostawa kurierem albo paletowa
| Distance of extraction slot |
|---|
| 17mm |
| Fatigue load limit, axial | 1 730N |
|---|
| Fixing holes diameter | 6,8mm |
|---|
| Limiting speed for grease lubrication | 8 200 1/min |
|---|
| Marketing category | XL |
|---|
| Mass moment of inertia | 0,102kg*cm² |
|---|
| Maximum diameter of housing | 35mm |
|---|
| Minimum chamfer dimension | 0,6mm |
|---|
| Minimum chamfer dimension | 0,3mm |
|---|
| Minimum diameter shaft | 20mm |
|---|
| Number of holes in adjacent construction | 3 |
|---|
| Outside diameter lower tolerance | -0,01mm |
|---|
| Outside diameter upper tolerance | 0mm |
|---|
| Pitch circle diameter fixing holes | 46mm |
|---|
| Pitch quantity of fixing holes | 3 |
|---|
| Pitch separation angle of holes in adjacent construction | 120° |
|---|
| Pitch separation angle of fixing holes | 120° |
|---|
| Position tolerance of bore in the housing | 0,1mm |
|---|
| Recommended INA precision locknut for axial locking | AM15 |
|---|
| Recommended INA precision locknut for radial locking | ZM15 |
|---|
| Required locknut force axial | 5 484N |
|---|
| Rib diameter inner ring | 28mm |
|---|
| Rigidity axial | 400N/µm |
|---|
| Size of fixing screws | M6 |
|---|
| Thermally safe operating speed | 3 500 1/min |
|---|
| Tightening torque for the recommended INA precision locknut | 10Nm |
|---|
| Tilting rigidity | 65Nm/mrad |
|---|
| Tolerance class | Standard |
|---|
| Width lower tolerance | -0,25mm |
|---|
| Width of extraction slot | 3mm |
|---|
| Width upper tolerance | 0mm |
|---|
| Sealing | 2RS |
|---|
