209,96 zł
Plummer block housing unit LSHE..-N, RIBB cast iron SHE
| Class description short | Plummer block housing unit |
| Mass netto | 0.61 kg |
| Operating temperature min. | -40.0 °C |
| Operating temperature max. | 180.0 °C |
| Basic dynamic load rating, radial | 14900.0 N |
| Basic static load rating, radial | 7800.0 N |
| REACH | REACH conform |
| RoHS | RoHS compliant |
| Bearing designation | GE25-XL-KLL-B |
| Bore diameter | 25.0 mm |
| Brand | INA |
| Connection thread for lubrication | M6 |
| Distance of raceway to locking collar | 27.0 mm |
| Distance fixing bore | 50.8 mm |
| Distance shaft axis | 36.5 mm |
| Bearing sealed | Yes |
| Bearing sort | RIBB |
| Bearing split | No |
| Housing opening | durchgehend |
| Housing in kit | LSHE25-N |
| Housing material | GG |
| Housing shape | Fuss_kurz |
| Housing sort | Plummer |
| Housing split | Nein |
| Location on shaft | Acc |
| Housing qty bolts | 2 |
| Sealing type | LIP |
| Height | 70.0 mm |
| Housing | GEHSHE05-GG-N |
| Length total | 70.0 mm |
| Locking collar total width | 44.5 mm |
| Material | GG |
| PFAS | nein |
| Protecting cap | KASK05 |
| Thread fixing bore | M10 |
| Width (base) | 36.0 mm |
| Width (head) | 21.0 mm |
| Groove | N |
