Angular contact ball bearing units ZKLR..-2RS, double direction, for screw mounting, lip seals on both sides
| Class description short | Flanged housing unit |
| Mass netto | 0.12 kg |
| Basic dynamic load rating, radial | 13600.0 N |
| Basic static load rating, radial | 8500.0 N |
| REACH | REACH conform |
| RoHS | RoHS compliant |
| Axial runout | 7.0 µm |
| Basic dynamic load rating, axial | 13200.0 N |
| Basic static load rating, axial | 17900.0 N |
| Bearing friction torque | 0.16 Nm |
| Bore diameter | 12.0 mm |
| Bore diameter lower tolerance | -0.007 mm |
| Bore diameter upper tolerance | 0.0 mm |
| Bore distance height | 38.0 mm |
| Bore distance width | 32.0 mm |
| Brand | INA |
| Diameter shaft shoulder | 14.0 mm |
| Fatigue load limit, radial | 445.0 N |
| Fixing boring diameter | 6.6 mm |
| Flange width | 44.0 mm |
| Bearing sealed | Yes |
| Housing in kit | ZKLR1244-2RS |
| Sealing type | LIP |
| Height flange | 50.0 mm |
| Height housing | 22.0 mm |
| Height housing lower tolerance | -0.5 mm |
| Height housing upper tolerance | 0.0 mm |
| Inner ring width lower tolerance | -0.25 mm |
| Inner ring width upper tolerance | 0.25 mm |
| Locknut 1 | ZM12 |
| Mass moment of inertia | 0.0102 kg*cm² |
| Minimum support diameter outer ring outside | 32.0 mm |
| Minimum chamfer dimension | 0.3 mm |
| Number of screws | 4.0 |
| Outside diameter bearing pot lower tolerance | -0.01 mm |
| Outside diameter bearing pot upper tolerance | 0.03 mm |
| Outside diameter bearing pot | 35.45 mm |
| PFAS | nein |
| Position bore in the housing | 0.2 mm |
| Rib diameter inner ring | 16.6 mm |
| Rigidity axial | 170.0 N/µm |
| Screw size | M6 |
| Support diameter outer ring inside | 27.0 mm |
| Tightening torque nut | 8.0 Nm |
| Width, inner ring | 20.0 mm |
| Sealing | 2RS |
